The SC UNO 4M PS is both a stationary and a portable unit. It is simple and intuitive to use and a cost effective fixed installation on the wall or used as a portable model, carried from site to site to different working places. Delivered with all accessories for immediate use.
Designed for heavy duty cleaning tasks the SC UNO 4M PS serie is a reliable choice for light agriculture, building and construction and automotive areas, etc.
The key objective is to deliver one unique versatile machine for professionals with different demands as to cleaning environment.
Powered by 1450 rpm high efficiency motor (50 Hz)
Brass pump head
3 ceramic coated pistons
Pressure activated unloader system
Enclosed oil system
Robust, steel transport handle
The unit can operate both in vertical and in horizontal position
Light weight (compared to competition)
Robust steel handle for easy transport
Pump pressure (bar/MPa) – 140 / 14
Cleaning impact (kg/force) – 2.7
Pump speed (RPM) – 1450
Power consumption (kW) – 2.9
Voltage / phase / frequency / current (V/~/Hz/A) – 230 / 1 / 50 / 12.5
Water flow Qmax / Qiec (L/h) – 620 / 560
Power cable length (m) – 5
Nozzle size – .0340
Max. inlet temperature (°C) – 60
Ceramic coated pistons – 3
Dimensions (L x W x H) (mm) – 480 x 240 x 340
Weight (kg) – 34
Recommended average hours of use per day – 3
