CAIZER | F80 | 4-POST HOIST

$0.00

CAIZER | F80 | 4-POST HOIST PRODUCT DETAILS

  • 8000kg SWL 4-Post Hoist

  • 1816mm Lifting Height

  • 2x 4000kg Jacking Bridges

  • Control post LHF or RHR Installation

  • Adjustable width platform

  • 4-Point Electric Safety Locks

  • 4-Point Wire Rope Failure Safety Locks

  • 8-Point Crossbeam Stabiliser Brackets

  • LED Lift Cycle Counter Display

  • Lockable Isolator & Emergency Stop

  • Optional: Bolt-on wheel alignment platform kit

CAIZER | F80 | 4-POST HOIST PRODUCT FEATURES

  • Platform Extension (300 mm)

  • Ramp Extension (600 mm)

  • Under-Car Parking Kit

  • Side Step

  • Turntable Storage Pocket

  • Drive-Thru Ramp

CAIZER | F80 | 4-POST HOIST PRODUCT SPECIFICATIONS

  • Model:  Caizer SMART F80

  • Safe Working Load:  Main Lift: 8000kg / Jack: 4000kg

  • Max. Lifting Height:  Main Lift: 1816 / Jack 340~350mm

  • Min. Height:  246mm

  • Lifting Time:  Main Lift: 40~60sec / Jack: 5~15sec

  • Lowering Time:  Main Lift: 35~55sec / Jack: 5~15sec

  • Motor:  3ph 2.2kw 415V 50HZ

  • Operating Method:  Control Box, Cable Remote Control

  • POWER:  3PH*5.5HP*4P*415v*50Hz/60Hz
                      1PH*2.4HP*4P*240v*50Hz/60Hz

CAIZER | F80 | 4-POST HOIST PRODUCT DETAILS

  • 8000kg SWL 4-Post Hoist

  • 1816mm Lifting Height

  • 2x 4000kg Jacking Bridges

  • Control post LHF or RHR Installation

  • Adjustable width platform

  • 4-Point Electric Safety Locks

  • 4-Point Wire Rope Failure Safety Locks

  • 8-Point Crossbeam Stabiliser Brackets

  • LED Lift Cycle Counter Display

  • Lockable Isolator & Emergency Stop

  • Optional: Bolt-on wheel alignment platform kit

CAIZER | F80 | 4-POST HOIST PRODUCT FEATURES

  • Platform Extension (300 mm)

  • Ramp Extension (600 mm)

  • Under-Car Parking Kit

  • Side Step

  • Turntable Storage Pocket

  • Drive-Thru Ramp

CAIZER | F80 | 4-POST HOIST PRODUCT SPECIFICATIONS

  • Model:  Caizer SMART F80

  • Safe Working Load:  Main Lift: 8000kg / Jack: 4000kg

  • Max. Lifting Height:  Main Lift: 1816 / Jack 340~350mm

  • Min. Height:  246mm

  • Lifting Time:  Main Lift: 40~60sec / Jack: 5~15sec

  • Lowering Time:  Main Lift: 35~55sec / Jack: 5~15sec

  • Motor:  3ph 2.2kw 415V 50HZ

  • Operating Method:  Control Box, Cable Remote Control

  • POWER:  3PH*5.5HP*4P*415v*50Hz/60Hz
                      1PH*2.4HP*4P*240v*50Hz/60Hz
